The "Tekla Pkpm Auto CAD Design Larger Span Modern Heavy Steel Structure Frame Workshop Garage Hangar" is a cutting-edge structural solution meticulously engineered by China CT Steel Structure Group Co., Ltd. This product leverages advanced software technologies like Tekla Structures, PKPM, and AutoCAD to design and deliver large-span heavy steel structures tailored for industrial workshops, garages, aircraft hangars, warehouses, and commercial buildings.
| Attribute | Value |
|---|---|
| Weather Resistance | Excellent |
| Processing | Cutting/Punching |
| Design Parameter | Wind Load, Snow Load and Earthquake |
| Intensity | High Intensity |
| Our Service | Design, Fabrication, Construction |
| Software | CAD, Tekla, Sketchup, Pkpm, Bim, etc |
| Structural Form | Portal Frame Structure |
| Weight | Customized Kg |
| Steel Grade | Q355 Q235B |
| Size | Customizable |
| Bolt | High Strength Bolt |
| Shape | According to customer requirements |
Utilizes Tekla Structures, PKPM, and AutoCAD for precise modeling, analysis, and design ensuring high accuracy in fabrication drawings and construction plans.
Spans up to 100 meters or more without internal supports, ideal for large open-space requirements in aviation, logistics, and manufacturing sectors.
Constructed using high-grade steel materials (Q345B/Q235B) that offer superior load-bearing capacity and resistance to wind, seismic activity, and extreme weather.
Flexible layout options based on client-specific needs with integration capabilities for insulation, roofing systems, skylights, and ventilation solutions.
Modular components allow for rapid installation and potential relocation, reducing overall project timeline and labor costs.
Lower maintenance and long-term operational costs with efficient use of materials that minimizes waste and optimizes budget allocation.
| Parameter | Details |
|---|---|
| Span Range | Up to 100 meters |
| Structural Type | Portal frame / Space truss / Rigid frame |
| Material Grade | Q345B, Q235B |
| Roof System | Sandwich panels / Corrugated steel sheets with insulation |
| Wall System | Composite wall panels / Insulated cladding |
| Design Standards | GB50017, AISC, Eurocode |
| Wind Load Resistance | Up to 0.85 kN/m² |
| Snow Load Capacity | Up to 0.7 kN/m² |
| Seismic Resistance | Level 8 |
| Service Life | 50+ years |
| Foundation Type | Bolted anchor / Embedded plate |
Designed to accommodate single or multiple aircraft with ease, featuring high clearance and wide openings for smooth access and egress.
Composed of floor slabs, primary and secondary beams, columns, and supports with spans of 6-8 meters between columns. Offers bearing capacity of 600KG-1000KG per square meter, maximizing warehouse space utilization and operational efficiency.
Features light weight, short construction period, and strong seismic resistance, enhancing rapid development and application of logistics facilities.
Suitable for car dealerships, service centers, and vehicle repair shops with customizable lighting, ventilation, and office modules.
Ideal for indoor arenas, exhibition centers, and event venues that support large crowds and temporary setups.
Perfect for storing farm equipment, feed, and livestock shelters with durability against harsh environmental conditions.
Rapid deployment capability for disaster relief operations with reusable and relocatable design for flexible usage.
At China CT Steel Structure Group Co., Ltd, we are committed to delivering high-performance steel structures that combine innovation, durability, and efficiency.
Contact us today to discuss your project requirements and discover how our advanced steel structure systems can support your vision!
