Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Farmshed86902
| Attribute | Value |
|---|---|
| Name | Quik Install Steel Structure Prefab Agricultural Buildings for Poultry House |
| Intensity | High Intensity |
| Weight | Light Weight |
| Stiffness | The Overall Stiffness Is Good |
| Homogeneity | The Material Has Good Homogeneity |
| Apply | Easy to Apply |
| Material | Steel |
| Wall Type | Steel Panel |
| Size | Customizable |
| Product Type | Agricultural Building |
| Classification | Material Name | Specification | Unit | Remarks |
|---|---|---|---|---|
| Main Structure | H-shaped Steel | Determined according to design span and bearing capacity, such as 300×300×10×15 | Ton | Used for main load-bearing frames, such as main beams and columns of greenhouses |
| C-shaped Steel | 160×60×20×2.5 | Ton | Used for purlins, connecting primary and secondary beams, and supporting roof and wall enclosure structures | |
| Angle Steel | ∠50×50×5 | Ton | Used to strengthen structural joints, supports, etc. | |
| Round Steel | φ12-φ20 | Ton | Used to make tension bars and struts to enhance structural stability | |
| Bolts, Nuts, Washers | 8.8-grade high-strength bolts, M16-M24, etc. | Set | Connect steel structure components | |
| Roof System | Color Steel Plate | 0.4-0.6mm thick, aluminized zinc or galvanized | Square Meter | Roof covering, with waterproof, anti-corrosion and thermal insulation properties |
| Thermal Insulation Cotton | 50-100mm thick, glass wool or rock wool | Cubic Meter | Laid on the inner layer of the roof to play a role in thermal insulation | |
| Self-tapping Screws | ST4.2×25-ST5.5×50 | Piece | Fix color steel plates to purlins | |
| Wall System | Color Steel Plate | Same specifications as roof color steel plate | Square Meter | Wall enclosure |
| Plastic-Steel Windows | Custom-sized according to design requirements | Square Meter | Used for ventilation and lighting | |
| Roller Shutter Door | Custom-sized according to the size of the door opening | Square Meter | Facilitate the entry and exit of agricultural machinery and agricultural products |
Spacious Design: Large span capability eliminates need for excessive support columns, maximizing usable space for flexible agricultural layouts.
Optimal Lighting: Strategic placement of lighting materials provides abundant natural light for crop growth and animal welfare.
Weather Protection: Color steel panels offer excellent waterproofing and corrosion resistance while reducing structural load.
Temperature Control: Thermal insulation regulates indoor climate, reducing energy consumption in both summer and winter.
Customizable Layouts: Structures can be tailored to specific livestock needs with integrated ventilation systems for optimal air circulation.
Easy Maintenance: Modular connection systems allow for simple disassembly and reassembly for future modifications or expansions.
Modern Integration: Compatible with smart monitoring systems and automated irrigation for precision agriculture.
China CT Steel Structure Co.,Ltd of BY GROUP is a comprehensive industrial group specializing in steel structure design, manufacture and installation with over 15 years of experience. Our 106,560 square meter factory produces a wide range of steel structures including:
Our "Quality and Service First" philosophy ensures every project meets the highest standards. We provide:
