Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Multistorey86101
| Attribute | Value |
|---|---|
| Name | Customized Multi Storey Steel Frame Construction Prefabricated |
| Construction Time | Short |
| Earthquake Resistance | High |
| Weight | Light Weight |
| Intensity | High Intensity |
| Stiffness | The Overall Stiffness Is Good |
| Design | Customized |
| Delivery | Customized |
The benefits of steel structure multi-storey buildings are numerous. Its high-strength steel can bear greater loads, support high-rise and complex structures, and achieve diversified designs. With high toughness and excellent seismic resistance, it can absorb energy through deformation in the face of earthquakes and other disasters, greatly ensuring the safety of personnel and reducing the risk of collapse.
The lightweight feature not only reduces the weight of the building itself, reduces the foundation requirements, but also makes transportation and installation more convenient. Because of its moldability and spatial flexibility, it can create a unique shape and provide an open and flexible interior space to meet various functional needs. Fast assembly and high precision enable the components to be quickly assembled on site after factory prefabrication, shorten the construction period and ensure stable quality.
| Name | Steel structure multi-storey building |
| Dimensions (Length) | H beam: 4000-15000mm |
| Thickness | Web plate: 6-32mm Wing plate: 6-40mm |
| Height | 200-1200mm |
| Color | According to customers |
| Size | MOQ is 200 m2, width * length * eave height |
| Base | Cement and steel foundation bolts |
| Main frame | H beam |
| Material | Q235B, Q345B or others as buyers' requests |
| Purlin | C or Z purlin: Size from C120~C320, Z100~Z20 |
| Bracing | X-type or other type bracing made from angle, round pipe |
| Bolt | Plain bolt and High-strength bolt |
| Roof & wall | Sandwich panel or color plate |
| Door | Sliding or rolling door |
| Window | Aluminium alloy window |
| Surface | Two layers of Anti-rust Painting or Hot Dip Galvanized |
| Sheet | 0.5mm or 0.6mm galvanized sheet |
| Accessories | Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, etc |
The high strength of steel gives the steel structure multi-storey building extraordinary bearing capacity. In high-rise urban areas, it can support dozens of floors of buildings, whether it is to withstand daily wind or occasional extreme weather loads. Complex structural forms, such as irregularly shaped building facades and large cantilevered structural sections, are also suitable for steel structures.
The high toughness and seismic resistance of steel structure multi-storey buildings provide excellent protection. When seismic waves hit, the microstructure inside the steel can be deformed in an orderly manner, gradually absorbing and dissipating the energy. This excellent seismic performance allows more time for evacuation, effectively reducing casualties and property losses.
The lightweight nature of steel structure has revolutionized building construction. Compared with traditional materials, the weight is greatly reduced, making foundation work simpler and construction costs lower. Prefabricated components with accurate dimensions enable rapid on-site assembly, significantly shortening construction periods.
The plasticity and spatial attributes of steel structures inspire creative designs. Whether sleek curves or geometric appearances, steel can handle it. The small cross-sectional size allows for open, column-free interior spaces that can be freely divided for various uses like offices, commercial spaces, or residences.
Our professional design team deeply understands customer needs, integrating material characteristics like high strength and moldability into each design. Using advanced software, we create unique shapes that meet both aesthetic and practical requirements.
We maintain long-term relationships with high-quality steel suppliers to ensure material excellence. Our logistics team plans efficient transportation routes using specialized equipment to deliver components safely and on time. The advantages of fast assembly and high precision enable rapid on-site construction, providing comprehensive high-quality service.
China CT Steel Structure Co.,Ltd of BY GROUP is a comprehensive industrial group specializing in steel structure design, manufacture and installation. Established over 15 years ago, our factory covers approximately 106,560 square meters.
Steel structural warehouse, workshop, high rise steel building, school, hotel, office building, exhibition building, show room, shopping mall, stadium, agricultural projects (stable/cattle barn, poultry house, pig house), car parking, hangar, shed, storage room, prefab house, container house, Sandwich panel, corrugated steel sheet, C&Z section steel, doors and windows, and cranes.
"Quality and service first" is our company's development goal. We look forward to developing together and winning more projects together!
For quality problems, claims must be made within 50 days of goods arrival. For quantity shortages, claims must be made within 10 days. All claims must include an inspection report from a reputable public surveyor. We will respond to valid claims within 20 days with proposed solutions.
