Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Hangar87701
| Attribute | Value |
|---|---|
| Name | Prefab Metal Airplane Hangar |
| Toughness | Good Toughness |
| Industrialization | High Degree of Industrialization |
| Period | The Construction Period Is Short |
| Wind Resistance | High |
| Snow Load Capacity | High |
| Size | Customizable |
| Material | Steel |
| Usage | Aircraft Hangar |
Our prefabricated metal aircraft hangars offer superior strength and durability for protecting valuable aircraft assets. The steel structure provides exceptional performance in all weather conditions while offering design flexibility and cost efficiency.
| Material Category | Specific Material | Specification | Purpose |
|---|---|---|---|
| Main Structure Steel | H-shaped Steel | Section dimensions determined by design calculation (e.g., 400mm×200mm×8mm×13mm) | Forms the main load-bearing frame (steel columns and beams) |
| Main Structure Steel | Channel Steel | 10# channel steel (height 100mm, leg width 48mm, waist thickness 5.3mm) | Supporting and connecting parts to enhance stability |
| Main Structure Steel | Angle Steel | Common ∠50×50×5mm | Joint connection and stiffening parts |
| Roof Materials | Color Steel Plate | Thickness 0.5mm - 0.8mm, width ~1m | Roof covering for waterproofing and heat preservation |
| Wall Materials | Color Steel Plate | Similar to roof specifications | Forms the hangar walls |
| Connection Materials | High-strength Bolts | M16 - M30 specifications | Main frame connections for structural integrity |
China CT Steel Structure Co.,Ltd of BY GROUP is a comprehensive industrial group specializing in steel structure design, manufacture, and installation with over 21 years of experience. Our 30-hectare facility produces a wide range of steel structures including:
We implement efficient packing methods using steel pallets for quick unloading and provide detailed loading documentation for each shipment.
We are a manufacturing factory providing complete design, production, and installation services with competitive pricing.
Contact us via email, phone, or messaging platforms for prompt response and project evaluation.
Inspections are welcome at any time, with real-time video options available for remote verification.
Yes, we offer complete design solutions using industry-standard software (AutoCAD, PKPM, etc.).
We accept T/T, L/C, and other negotiable payment methods.
Delivery schedules vary based on project scale and complexity.
