Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Hangar87701
| Attribute | Value |
|---|---|
| Name | Steel Building Aircraft Hangar |
| Usage | Aircraft Hangar |
| Intensity | High Intensity |
| Weight | Light Weight |
| Stiffness | Excellent Overall Stiffness |
| Material | Steel |
| Customization | Available |
| Size | Customizable |
| Wall Type | Metal Cladding |
| Installation | Fast Assembly |
| Roof Type | Sloping |
Originally developed for smaller aircraft with simple parking requirements, steel structure hangars have evolved significantly with the aviation industry's growth. Modern steel structures now accommodate larger aircraft fleets through innovative designs using high-performance steel, offering superior strength and expandability.
Advancements in steel technology have enhanced fire resistance and corrosion protection, while digital design and construction techniques ensure precision and efficiency. These developments enable steel hangars to meet diverse modern aviation requirements while progressing toward intelligent and eco-friendly solutions.
| Material Category | Specific Material | Specification | Quantity | Purpose |
|---|---|---|---|---|
| Main Structure Steel | H-shaped Steel | 400mm×200mm×8mm×13mm (typical) | Project-specific | Primary load-bearing frame (columns/beams) |
| Channel Steel | 10# (100mm×48mm×5.3mm) | As required | Structural support and connections | |
| Angle Steel | ∠50×50×5mm | As required | Joints and stiffening | |
| Round Steel | Ø20mm | As required | Auxiliary structural components | |
| Roof Materials | Color Steel Plate | 0.5mm-0.8mm thickness | Roof area calculation | Waterproof roof covering |
| Thermal Insulation Cotton | 50mm-100mm thickness | Roof area calculation | Thermal insulation | |
| Self-tapping Screws | Ø4.8mm-6.3mm | High quantity | Panel fastening | |
| Wall Materials | Color Steel Plate | Similar to roof | Wall area calculation | Wall construction |
| Thermal Insulation Cotton | Same as roof | Wall area calculation | Wall insulation | |
| Doors and Windows | Aluminum/steel | Custom | Access points | |
| Sealing Rubber Strips | Custom | As required | Weatherproofing | |
| Connection Materials | High-strength Bolts | M16-M30 | Node calculation | Primary frame connections |
| Ordinary Bolts | M8-M12 | High quantity | Auxiliary connections | |
| Welding Materials | E4303 electrodes | Project-specific | Steel welding | |
| Fireproof Materials | Fireproof Coating | Type by fire rating | Surface area calculation | Fire protection |
Our steel structure solutions combine professional expertise, quality craftsmanship, and efficient execution to deliver exceptional value for your construction projects.
China CT Steel Structure Co., Ltd of BY GROUP is an established industrial group with over 21 years of experience in steel structure design, manufacturing, and installation. Our 30-hectare facility produces a comprehensive range of steel buildings including:
We optimize logistics with efficient container loading systems that include detailed packing lists and material organization for simplified on-site assembly. Our commitment to "Quality and Service First" drives continuous improvement and successful project partnerships.
We are a manufacturing factory providing complete one-stop services with competitive pricing.
Contact us via email, phone, or messaging platforms for prompt response.
Inspections are welcome at any time, with real-time video options available.
Yes, we create complete solution drawings using industry-standard software.
We accept T/T, L/C, and other negotiable payment methods.
Delivery schedules vary based on project size and specifications.
