Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Farmshed86902
| Attribute | Value |
|---|---|
| Product Name | Thermal Insulation Prefab Steel Framed Agricultural Buildings Lightweight |
| Name | Prefab Farm Buildings |
| Insulation | Available |
| Snow Load | Up to 1.5kN/m² |
| Wall Type | Single/Double Layer |
| Intensity | High Intensity |
| Weight | Light Weight |
| Stiffness | Excellent Overall Stiffness |
| Homogeneity | Superior Material Homogeneity |
| Application | Easy to Apply |
Modern steel structure farms have revolutionized agricultural facilities with their durability, rapid construction, and flexible layouts. These structures incorporate advanced design features to withstand local climate conditions while integrating energy-efficient lighting and intelligent ventilation systems for optimal agricultural production.
| Classification | Material Name | Specification | Unit | Remarks |
|---|---|---|---|---|
| Main Structure | H-shaped Steel | 300×300×10×15 (varies by design) | Ton | Primary load-bearing frames for beams and columns |
| C-shaped Steel | 160×60×20×2.5 | Ton | Purlins and connecting beams for roof/wall support | |
| Angle Steel | ∠50×50×5 | Ton | Structural joint reinforcement and supports | |
| Round Steel | φ12-φ20 | Ton | Tension bars and struts for enhanced stability | |
| Bolts, Nuts, Washers | 8.8-grade high-strength, M16-M24 | Set | Component connection hardware | |
| Roof System | Color Steel Plate | 0.4-0.6mm thick, aluminized zinc/galvanized | m² | Waterproof, anti-corrosion roof covering |
| Thermal Insulation Cotton | 50-100mm thick, glass wool/rock wool | m³ | Roof insulation layer | |
| Self-tapping Screws | ST4.2×25 - ST5.5×50 | Piece | Color steel plate fasteners | |
| Wall System | Color Steel Plate | Same as roof specifications | m² | Wall enclosure material |
| Plastic-Steel Windows | Custom-sized | m² | Ventilation and natural lighting | |
| Roller Shutter Door | Custom-sized | m² | Agricultural machinery access |
Our expert design team creates customized solutions tailored to local climate conditions and specific agricultural requirements. We implement rigorous quality control throughout manufacturing, from material selection to final inspection, ensuring durable, high-performance structures.
China CT Steel Structure Co., Ltd of BY GROUP is an established industrial group specializing in steel structure design, manufacturing, and installation with over 15 years of experience. Our 106,560m² facility produces a comprehensive range of steel structures including:
