Place of Origin:
China
Brand Name:
CT Steel Structure
Certification:
SGS
Model Number:
Hangar87701
| Attribute | Value |
|---|---|
| Name | Prefab Hangar Buildings |
| Customization | Available |
| Size | Customizable |
| Wall Type | Metal Cladding |
| Installation | Fast |
| Roof Type | Sloping |
| Weight | Light Weight |
| Intensity | High Intensity |
| Stiffness | The Overall Stiffness Is Good |
| Material Category | Specific Material | Specification | Purpose |
|---|---|---|---|
| Main Structure Steel | H-shaped Steel | Section dimensions determined by design calculation (e.g., 400mm×200mm×8mm×13mm) | Form the main load-bearing frame of the aircraft hangar |
| Main Structure Steel | Channel Steel | 10# channel steel (height 100mm, leg width 48mm, waist thickness 5.3mm) | Used for supporting and connecting parts to enhance stability |
| Main Structure Steel | Angle Steel | Common ∠50×50×5mm | Used for joint connection and stiffening |
| Roof Materials | Color Steel Plate | Thickness 0.5mm - 0.8mm, width about 1m | Roof covering layer for waterproofing and heat preservation |
| Wall Materials | Color Steel Plate | Similar to roof specifications | Form the walls of the aircraft hangar |
| Connection Materials | High-strength Bolts | M16 - M30 specifications | Connection of main frame to ensure strength |
