Place of Origin:
China
Brand Name:
CT Steel Structure
Model Number:
Steel Structure Bridge
| Attribute | Value |
|---|---|
| Name | Modular Steel Truss Bridge Construction Lightweight With Good Stiffness |
| Install | Online Guidance, Support Installation |
| Residential Wall Structure | Wallboard |
| Life | Semi-Permanent Bridge |
| Material | Steel Bridge |
| Origin | China |
| Weight | Lightweight |
| Stiffness | The Overall Stiffness Is Good |
Live loads such as vehicles and people, as well as constant loads such as the dead weight of the bridge, are first transmitted from the deck to the longitudinal beams and beams, and then converged to the main beams. The main beam transfers the load in the form of bending and shearing to the piers and abutments, and finally to the foundation. In this process, the high strength characteristics of steel enable the structure to withstand loads efficiently. By reasonably designing the mechanical model and member size of the structure, the stress of each component under different load conditions is ensured to be within a safe range.
| Scale | Large Bridge | Surface Treatment | Shot Blasting, Galvanized or Painted |
|---|---|---|---|
| Material | Steel Bridge | Lead Time | 35-50 Days |
| Secondary Frame | Tie Bar, Bracing, Diagonal Rod for Bridge | Shot Blasting Standard | SA2.0~2.5 |
| Life | Permanent Bridge | Welding | Continuous Weld Full Length |
| Cutting | Plasma Cutting, CNC Cutting | Transport Package | Steel Pallet+Container |
| Pre-Assembly | Pre-Assembly in Our Factory | Install | Online instruction |
| Specification | L*W*H | Size | Customizable |
| Main Frame | H Beam and Column, Lower Chord Brace |
Steel structures have low density and are much lighter than concrete bridges under the same bearing requirements. This reduces the requirements for foundation bearing capacity, reduces the scale and cost of foundation projects, and facilitates transportation and installation in areas with complex terrain and difficult construction.
Cross-river and cross-river bridges: Like Shanghai Nanpu Bridge, it adopts the form of a steel structure cable-stayed bridge connecting Pudong and Puxi. It is an important transportation hub in the city, greatly alleviating cross-strait traffic pressure and promoting interregional exchanges and development.
